繁體中文 · English A REST API allowing websites, Discord bots and dashboards to read live data from your Minecraft server.

curl http://localhost:8080/api/v1/status

{
  "ok": true,
  "data": { "online": ["40094f2f-…", "8b1e…"], "minecraft": 2, "discord": 3400 },
  "meta": { "version": "v1", "server": "global", "updatedAt": 1784300000000, "cachedAt": 1784299700000 }
}

Every player field is a UUID.

Highlights

• Never blocks the main thread — data that is only safe to read on the main thread is snapshotted there on a timer; HTTP requests only ever read the cache, so traffic cannot drag down TPS
• Per-endpoint access control — decide which endpoints need a key, and which fields stay hidden even on public endpoints
• Punishments kept forever — bans, tempbans, kicks, warnings, mutes and jails remain in the history after they are lifted
• Built-in rate limiting — token bucket, with correct client-IP resolution behind Cloudflare or Nginx
• No runtime dependencies — the HTTP layer uses the JDK's built-in server and JSON is serialised in-house
• Fully bilingual — English and Traditional Chinese across the config, console, commands and API output

Installation

1. Drop ServerAPI-1.0.0.jar into plugins/
2. Start the server to generate plugins/ServerAPI/config.yml
3. Check http.port — the default 8080 often clashes with other services
4. curl http://localhost:8080/api/v1

Requires Paper 26.1 and Java 21 or newer. On first start Paper's PluginLoader downloads the database drivers (HikariCP / JDBC / Jedis) from Maven, so the first launch needs network access.

Endpoints

GET /api/v1 returns an index of every endpoint currently enabled.

Every endpoint is served at two paths. /api/v1/{endpoint} is the versioned path — use this for integrations. /api/{endpoint} is an alias that always points at the latest version.

Entity counts deliberately exclude players so they cannot leak who is online.

Response format

{ "ok": true,  "data": { … }, "meta": { … } }
{ "ok": false, "error": { "status": 404, "message": "…", "path": "…" }, "meta": { … } }

Branch on ok; the payload is always in data.

The two timestamps in meta differ:

updatedAt - cachedAt is how stale the payload is. For the real age of the data, use cachedAt.

Authentication

Send the key as an X-API-Key header, or as ?key= when auth.allow-query-key is on:

curl -H "X-API-Key: <key>" http://localhost:8080/api/v1/plugins
curl "http://localhost:8080/api/v1/plugins?key=<key>"

URLs end up in browser history and in reverse-proxy access logs. Use the header for real integrations.

Three layers of control:

Per endpoint — auth.require-key.<endpoint>. Anything not listed defaults to requiring a key, so a new endpoint is never public by accident.

Per field — auth.protected-fields.<endpoint> hides individual fields even when the endpoint is public. By default /player hides op, banned and discord: the first two are key-protected on /operators and /bans, and leaving them exposed is a back door — read online UUIDs from the public /status, then query /player one by one to rebuild both lists. Hidden fields are listed in meta.hiddenFields.

Disguised responses — with auth.hide-protected on, unauthorised requests get a 404 rather than a 401. Answering 401 tells an attacker that something worth protecting lives there and points them at it.

When auth.enabled is false the whole check is off and none of the above applies. Starting in that state logs a warning.

Rate limiting and reverse proxies

Token bucket: credit refills at a fixed rate and short bursts are allowed, but sustained overuse returns 429 with a Retry-After header. The default is 120 requests per minute per source IP with a burst of 30.

Behind Cloudflare, Nginx or Apache every visitor appears to come from the proxy, which throws the limiter off. Turn on real-ip.enabled to read the real address from proxy headers:

real-ip:
  enabled: true
  trusted-proxies:
    - "cloudflare"        # expands to every published Cloudflare range
    - "127.0.0.1/32"

Proxy headers are trivially forged, so they are only trusted when the connection itself comes from trusted-proxies. X-Forwarded-For is scanned right to left, skipping trusted proxies to reach the first address that is not one.

Punishment records

/punishments merges bans, IP bans, tempbans, kicks, warnings, mutes and jails, with statistics (total, players punished, currently active).

Records are kept permanently — lifted or expired entries stay listed with their status changed, which suits a public punishment lookup page. Set punishment-log.retention-days: 0 to never purge.

Neither Minecraft nor CMI stores kick history, so this plugin listens for the events itself; that means only kicks after it was enabled are covered.

Data comes from periodic reconciliation against the ban list and CMI rather than from intercepting commands, so punishments are recorded no matter what issued them.

Web pages

Three HTML pages, all off by default:

web:
  docs: false           # /api/docs                 Interactive API docs and try-it
  punishments: false    # /punishments?view=html    Punishment records demo page
  placeholders: false   # /placeholders?list=true   PlaceholderAPI preview page

These lay the content out in full for anyone who can open them, so consider carefully before exposing them publicly. When off, the path or parameter returns 404; the JSON endpoints are unaffected.

/api/docs lists every enabled endpoint and parameter, lets you fire real requests from the page, and includes an API key field that never leaves your browser.

Storage

History, the player stat cache and the punishment log all go to a database, which is the single source of truth.

storage:
  type: sqlite          # sqlite · mysql · mariadb

Redis is optional: reads prefer Redis, writes go to the database first and then overwrite Redis. If Redis dies the plugin falls back to the database without interruption and backfills on reconnect.

On a single server with a remote Redis, the local database is usually faster. Redis mainly pays off for cross-server aggregation.

Offline players require re-reading the stats file (~425ms measured, versus ~4ms for online players), so only offline players are cached. Entries live in Redis or the database and use no server memory.

Multi-server

Several servers can share one Redis and database, separated by server-id. Servers on the same cluster-id discover each other, and /network aggregates the whole network.

Key       {namespace}:{cluster-id}:{server-id}:{type}[:{id}]
Single    serverapi:::history
Network   serverapi:main:survival:history

server-id defaults to global, meaning unset and treated as standalone. When several servers share one Redis each must get a unique value, otherwise they overwrite each other's data — the plugin warns about this at startup.

Languages

English and Traditional Chinese are built in, covering config comments, console messages, command replies and API output. Player-supplied text such as ban reasons and nicknames is never translated.

language: auto detects from the host locale and writes the result back on first start. Switch with:

/serverapi lang en_US

Switching backs up the existing config, then rebuilds it from the new language's template with every value preserved. Language files live in plugins/ServerAPI/lang/ and can be edited; keys added in later versions are filled in automatically from the bundled copy.

Integrations

All optional soft dependencies. When a plugin is missing its fields are null and nothing else breaks.

/placeholders is the only endpoint that dispatches to the main thread, since most expansions need Bukkit API access. It is bounded by a timeout and answers 504 if it expires.

Commands and permissions

Snapshot intervals

Tuned per endpoint by how fast the data changes versus what it costs to read (cache in config.yml, in ticks):

Licence

Free for non-commercial use; commercial servers need a separate licence. See LICENSE.

Issues: GitHub Issues
